Product Description:
One of the key advantages of our Water Gate Valve is its high flow
capacity. This means that it can handle large volumes of water
without causing any blockages or pressure drops in the pipeline.
Additionally, the valve has a low pressure loss, which helps to
maintain the overall efficiency of your system.
The valve features an outside screw and yoke (OS&Y) design,
which enables easy operation and maintenance. With this design, the
stem of the valve is located outside the body, allowing for quick
and easy replacement of parts without having to disassemble the
entire valve. This feature also ensures that there is no
contamination of the water supply by the lubricant used in the
valve.
Our Water Gate Valve also comes with soft sealing, which provides a
tight seal and prevents any leakage. The valve is tested and
certified to EN1074-2 standards, ensuring that it meets the highest
quality requirements for water supply systems. The end connections
of the valve are available in ANSI and GB standards, providing
flexibility and compatibility with various piping systems.
Overall, our Water Gate Valve is an excellent choice for
controlling water flow in your piping system. Its high flow
capacity, low pressure loss, and easy maintenance make it a
reliable and efficient option for various applications. With its
soft sealing, OS&Y design, and EN1074-2 certification, you can
be sure that you are getting a high-quality valve that meets the
highest industry standards.
Features:
- Product Name: Water Gate Valve
- Pressure Rating: PN10,PN16,PN25
- Application: Water
- Operation: Manual, Electric
- Connection: Flanged
- Features: Corrosion Resistance, Durable, Low Maintenance
- WRAS Approved
- Gate Valve
- EN1074-2
Technical Parameters:
| Technical Parameters | Values |
|---|
| Product Name | Water Gate Valve |
| Size | 2-32 Inches |
| Connection | Flanged |
| Features | Corrosion Resistance, Durable, Low Maintenance |
| Pressure Rating | PN10, PN16, PN25 |
| Application | Water |
| Design Standard | ANSI, BS |
| Material | Cast Iron, Stainless Steel |
| End Connection | ANSI, GB |
| Operation | Manual, Electric |
| Additional Features | With Top Cap Or Handwheel, Outside Screw Yoke, Soft Sealing |
Applications:
The valve is equipped with NBR or EPDM seals, which provide
excellent sealing performance, making it suitable for various
applications. It has a pressure rating of PN10, PN16, or PN25,
depending on the model, and is designed to meet the ANSI or BS
standard. The valve is available in sizes ranging from 2 to 32
inches, making it suitable for various pipeline systems.
The AFC Water Gate Valve is suitable for various product
application occasions and scenarios, including:
- Water Treatment Plants: The valve is ideal for regulating water flow in water treatment
plants. It can help control the water pressure and prevent water
leakage, ensuring that the water treatment process is efficient and
effective.
- Water Supply Systems: The valve is also suitable for water supply systems. It can help
regulate the flow of water, prevent water hammer, and ensure that
the water supply is stable and reliable.
- Water Distribution Networks: The valve is also suitable for water distribution networks. It can
help control the flow of water in pipelines, prevent water leakage,
and ensure that the water distribution system is efficient and
reliable.
- Industrial Applications: The valve is also suitable for various industrial applications. It
can help regulate the flow of water in pipelines, prevent water
leakage, and ensure that the industrial process is efficient and
reliable.
In addition, the AFC Water Gate Valve is coated with epoxy to
ensure that it is resistant to corrosion and rust. It is also
compliant with the EN1074-2 standard, ensuring that it meets the
required quality standards. With its high-quality materials,
excellent sealing performance, and reliable design, the AFC Water
Gate Valve is a great choice for various product application
occasions and scenarios.
FAQ:
A: The brand name of the water gate valve product is AFC.
Q: What are the model numbers available for the water gate valve
product?
A: The available model numbers for the water gate valve product are
GBCX, GBBX, and GBHX.
Q: Where is the water gate valve product manufactured?
A: The water gate valve product is manufactured in China.
Q: What type of water system is the water gate valve product
suitable for?
A: The water gate valve product is suitable for use in both
residential and commercial water systems.
Q: What is the material used to make the water gate valve product?
A: The water gate valve product is made of high-quality materials
to ensure durability and longevity.
